20 / 5 Micron Film PVDF Color Coated Aluminum Coil / Aluminum Sheet 1050 3003 5005

Brand Name:	JERO
Model Number:	JC1
MOQ:	10 tons
Price:	2800-2930USD/TON
Packaging Details:	Seaworthy Standard Export Package
Payment Terms:	L/C,T/T,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

HENAN, CHINA

Certification:

SONCAP SABER ISO CE

Type:

Coated Aluminum Coil

Material:

1050/3003/5005 Etc

Surface:

Bright Finish

Coating:

PVDF

Gloss:

Standard 25+1-5

Front Coating:

20-25 Microns

Back Coating:

5+5 Microns

T Bend:

1T Bending,no Paints Off

Highlight:

PVDF color coated aluminum coil

1050 coated aluminum coil

3003 coated aluminum coil

Product Description

20 / 5 micron film PVDF color coated aluminum coil aluminum sheet

Color coated aluminum sheet is based on the material of Series 1060.1100,3003, 3004,5052,etc,

after temperature control and special technical treatment getting better adhesion.

Now itis widely used in aluminum-plastic panel,plate,honeycomb panel, ceiling, roofing, and electronic products.

It could be used for over 30 years with its stable performance,anti-corrosion and less weight.

20 / 5 Micron Film PVDF Color Coated Aluminum Coil / Aluminum Sheet 1050 3003 5005 0

It has these advantages than coated steel coil

Light weight Aluminum specific weight is 66% lighter than steel. Due to its light

specific weight, aluminium is easy and inexpensive to ship.

Sustainable Aluminium is 100% recyclable and keeps its original characteristics

during the recycling process.

Corrosion resistant Color coated aluminum coil can form alumina film with the atmosphere

to prevent the further corroded.

Deformability Color aluminum have the better weldability and ductility.

20 / 5 Micron Film PVDF Color Coated Aluminum Coil / Aluminum Sheet 1050 3003 5005 1

Basic Parameters

Product Name	PVDF Color Coated Aluminum Coil
Material	Aluminum Alloy (e.g., AA3003, AA3004, AA3105)
Coating Information	PVDF
Size	Width:500mm-1600mm
Color	RAL standard color card or according to your sample
Application	Construction: Roofing, wall panels, curtain walls,ceilings etc
Reverse impact	9J pants,no paints off
Pencil hardness	≥HB
Organic Solvent resistance	Butanone MEK wipes 100 times,no paints breakage
Scratch resistance	Probe scratch meter test weight 1000 grams,no paints breakage
Humidity and heat resistance	Non-condensing humidity and heat test chamber is placed for 1000 hours, no bubbles,cracks,breakage, no change of color, gloss and hardness.
Boiling water resistance	100°boiling water bath for 2 hours,no loss of light,discoloration,cracking,foaming,falling off and other phenomena

Professional equipment

The company has four coating production lines,which include three coil roller coated production lines, one sheet coating produc-tion line.The annual capacity can achieve 50,000 tons. Besides,the company has one of the most advanced aluminum veneertion line ,with an annual output of one million square meter. In addition,the company also has two column slitting machines, two cutting machines,two embossing machines,which mainly engaged in color coated aluminum coil,aluminum magnesium manganese metal roof panels,curtain wall aluminum veneer, metal antique tiles and a variety of stone,wooden grain roller coated aluminum and related coated aluminum products production and development. More importantly, we have exceeded 5.0 mm utra-thick,1800 ultra-wide production in China.

20 / 5 Micron Film PVDF Color Coated Aluminum Coil / Aluminum Sheet 1050 3003 5005 2
