Durable and Vibrant Color Coated Steel Coils for Different Applications

Brand Name:	JERO STEEL

Detail Information

Product Description

Detail Information

Place of Origin:

China

Brand Name:

JERO STEEL

Certification:

ISO9001 SABER SONCAP SNI BIS QM

Surface:

Bright/Wrinkle/Matt

Width:

25-1500mm

Back Coating:

5-7micron

Yield Strength:

195-420MPA

Paint Type:

PE/SMP/HDP/PVDF

Top Coating:

5+20micron

Color:

Ral Standard Color / Customized

Standard:

ASTM A755/CGCC/EN 10346

Highlight:

ISO9001 Color Coated Steel Coils

508mm Color Coated Steel Coils

EN 10346 Color Steel Coils

Product Description

Product Description:

Pre-painted steel is a bare metal substrate or corrosion-resistant substrate with paint applied to both sides through a continuous coil coating process.

In this process, the metal is unwound, cleaned, and chemically treated, resulting in a uniform paint finish. Furthermore, pre-painted metal is formed by applying a protective film to a metal substrate such as steel or aluminum via the coil coating process. This process involves the cleaning and chemical treating of both the top and bottom surfaces, followed by the priming and/or painting of the metal, and then the curing in an oven.

A large range of coatings are currently in use due to their distinctive levels of durability and performance as well as fulfilling aesthetic requirements.

Features:

Advantages of Prepainted Steel Coil

One of the top advantages of using pre-painted steel coil is it's corrosion resistance. This allows the product to last longer and be a reliable, long-term solution. Additionally, the product looks great and is cosmetically appealing. This combination of strength of the steel with the corrosion resistance of the metallic coating combined with its aesthetic appeal is what makes this type of product so unique.

Customization is another important aspect when considering pre-painted steel coils. Variations such as color, coating thickness, paint vendor, etc. is very accommodating and allows for optimal satisfaction. Additionally, this product allows for more economical yield in roll formed applications due to the time saved painting after the forming.

Technical Parameters:

Property	Value
Top Coating	5+20micron
Tensile Strength	270-500MPA
Baseplate	Galvanized or Galvalumed
Surface Structure	Big/Small/Zero/Regular Spangle
Paint Type	PE/SMP/HDP/PVDF
Coating	Zinc Coated and Paint
Zinc Coating	Z30-Z275GSM
Coil ID	508mm/610mm
Width	25-1500mm
Thickness	0.12-2mm

Applications:

Application areas have many diverse uses. The construction industry utilizes this technology for the manufacture of exterior and Interior products such as metal shingles, corrugated sheeting, sandwich panels, profiles, metallic ceilings, skirting boards, and decorative panels inside heated and non-heated rooms, elevators, doors, window shutters, shelves, etc. The automotive industry also makes use of this technology to develop external and internal car body parts, such as car doors, car boots, oil filters, dashboards, and windscreen wipers. Furthermore, this technology is used for the manufacture of home appliances, furniture, and consumer goods such as metallic furniture, lighting equipment, shelves, radiators, car doors, and car boots.

Customization:

Our coated galvanized coil is of high quality and available in a variety of sizes and shapes. Brand Name: JERO STEEL, Place of Origin: China, Certification: ISO9001 SABER SONCAP SNI BIS QM, Coating: Zinc Coated And Paint, Top Coating: 5+20micron, Thickness: 0.12-2mm, Paint Type: PE/SMP/HDP/PVDF, Coil Weight: 3-8 Tons.

Packing and Shipping:

Packaging and Shipping of Color Coated Steel Coil

Color Coated Steel Coils are packaged and shipped following industry standard practices and regulations.

The coils are wrapped in either plastic sheet or thin foam.
The coils are then placed in a wooden box or steel box.
The boxes are then placed on a pallet and secured with straps.
The pallets are then placed in a truck or container for transport.

Tags:

Printed Ppgi Coil ISO9001,

Ral Printed Ppgi Coil,

Wall Panel galvanized steel coil ppgi
