ASTM AZ150 0.4x1200mm Aluzinc Galvalume Steel Coil For Outdoor Metal Paneling

Brand Name:	JERO STEEL
Model Number:	JS101
MOQ:	20 tons
Price:	US$560-590 Per Ton
Packaging Details:	3 layers water proof standard export package
Payment Terms:	Western Union,MoneyGram,T/T,L/C

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001 SABER CNCA SGS FORM F FTA

Standard:

S550GD/ASTM A792/JIS G3321

Thickness:

0.12-3mm

Width:

600-1500mm

Aluminium Content:

Surface:

Chromated/AFP

Coil Weight:

2-8 Tons As The Request

Supply Ability:

500 ton per day

Highlight:

Galvalume Steel Coil Outdoor Metal Paneling

0.4x1200mm aluzinc galvalume steel coil

AZ150 aluzinc galvalume steel coil

Product Description

ASTM AZ150 0.4x1200mm Aluzinc Galvalume Steel Coil Chinese Supplier

Aluminum-Zinc coated steel coil is an advanced corrosion-resistant steel product manufactured

by hot-dip coating a cold-rolled or hot-rolled steel substrate with an alloy composed of 55% alu

-minum, 43.4% zinc, and 1.6% silicon. Known commercially as Galvalume, it combines aluminum’s

oxidation resistance with zinc’s sacrificial protection, making it superior to traditional galvanized steel

(GI) in harsh environments.

Composition

Base Material: Cold-rolled or hot-rolled steel (low-carbon steel).

Coating: An alloy of 55% aluminum, 43.4% zinc, and 1.6% silicon (common grades: AZ150,

AZ100, where the number indicates coating weight in g/m²). Silicon prevents brittle interme

-tallic formation between the coating and steel.

Product Specifications & Standards

Parameter	Typical Range	Int’l Standards
Base Thickness	0.2-3.0 mm	ASTM A792 (USA)
Coating Weight	AZ60-AZ180 (total both sides)	JIS G3321 (Japan)
Coil Width	600-1500 mm (custom slitting available)	GB/T 14978 (China)
Surface Finish	Smooth/matte/embossed/pre-painted	EN 10346 (Europe)

Key Properties

Corrosion Resistance

Aluminum forms a dense oxide layer (Al₂O₃), resisting acids, alkalis, and moisture. Service

life is 2–6 times longer than regular galvanized steel. Zinc provides sacrificial protection, pr

-eventing rust even if the coating is scratched.

Heat Resistance

Withstands 300–500°C (aluminum’s high melting point: 660°C), whereas galvanized steel degrades

above 200°C.

Reflectivity & Aesthetics

Silver-gray surface reflects ≥80% of solar radiation, ideal for roofing. Can be painted (pre-painted coils)

for decorative purposes.

Formability

Good adhesion for stamping and bending, but higher hardness may increase tool wear.

Applications

Architectural Cladding

Roofing/wall panels – leverages reflectivity + corrosion resistance

HVAC ducts (resists condensation)

Home Appliances

Air conditioner housings (used by Gree/Haier)

Oven cavities (Midea built-in ovens)

Automotive Components

Mufflers/exhaust pipes (requires modified AZ coating)

Agricultural Infrastructure

Greenhouse frames (resists fertilizer/pesticide corrosion)

ASTM AZ150 0.4x1200mm Aluzinc Galvalume Steel Coil For Outdoor Metal Paneling 0
